Peanut shell briquetting boiler Sawdust Fired Steam Boiler industrial biomass boiler cost
Peanut shell briquetting boiler has a high degree of automation,
stable operation, safe and reliable, and high service life
There are mainly DZH and DZL Sawdust Fired Steam Boiler.
DZH is hand fired boiler
DZL is automatically running boiler.
Customers can buy Sawdust Fired Steam Boiler as the budget.
Normally DZL industrial biomass boiler cost a little higher than the DZH model. But it has better working
condition and efficiency.
The second question we concern about is the running cost. What is
the running cost of the Peanut shell briquetting boiler?
Recently a lot of consultation burning biological particle boiler
users are asking the industrial biomass boiler cost, indeed, the cost of fuel is related to the competitiveness of an
enterprise and can adapt to the cost increase after coal is banned.
Peanut shells briquetting fuel belongs to a new type of
environmentally friendly fuel, is the main use of new type of
agriculture fruits of peanut shell, before processed into
briquetting peanut shell, peanut shell, has been a waste as peanut
shells briquette fuel, as a kind of environmental protection has
been a large number of used industrial boiler and heating in
winter, so the peanut shell briquetting fuel cost how much?
Please follow us for an account.
Take the cost of heating 50 tons of hot water at 42℃ as an example:
1 kg of water 1 degree of temperature need 1 calories, calculated
the water 10 degrees: heat up to 42 degrees need to heat up 42-10 =
32 degrees (Δ = 32 degrees) 50 tons of water = 50000 kg;1 degree of
warming =50000 X 1 CAL =50000 CAL;Temperature rise of 32 ° c =50000
kcal X 32=1600000 kcal;
1. coal-fired boilers
The calorific value of standard coal for coal-fired boilers is 5000
kcal/kg. According to the average coal price of each region,
1600000 kcal ÷5000 kcal X1.2 yuan =384 yuan is calculated according
to 1.2 yuan per kg. The thermal efficiency of coal-fired boilers is
generally 80%, 384÷0.8=480 yuan.Equal to USD
2. Sawdust Fired Steam Boiler
The calorific value of biomass particles on the market is 4000
kcal/kg, according to the biomass particles around 1 yuan per kg
calculated 1600000 kcal ÷4000 kcal X 1 yuan =400 yuan, the thermal
efficiency of biomass boiler is generally 80%, 400÷0.8=500 yuan.
It can be seen that the basic cost of burning biomass and
coal-fired boilers is the same, but biomass boilers are more
environmentally friendly. Please have a look at the relative
advantages and disadvantages of the product.
| Biomass fuel | coal |
| Volume | The compressed volume Save storage space Make it easier to transport Reduce transportation costs | Large volume Take up storage space High transportation cost |
| Combustion efficiency | High combustion efficiency Easy to burn out Small amount of residual carbon | Shoulds not be lit High volatile content High flash point |
| environmental protection or not | Not easily produced when burned Sulfur dioxide Phosphorus pentoxide and other harmful gases | Combustion chamber generation Sulfur dioxide Phosphorus pentoxide Lead to acid rain, pollution of the atmosphere, not environmental
protection |
| Quickly installed boiler |
| boiler model | Unit | DZL1-0.7/1.0-AII | DZL2-0.7/1.0-AII | DZL4-0.7/1.25/1.6-AII | DZL6-1.25/1.6-AII |
| capacity | ton/h | 1 | 2 | 4 | 6 |
| rated pressure | Mpa | 0.7/1.0 | 0.7/1.0 | 0.7/1.25/1.6 | 1.25/1.6 |
| rated steam temperature | ℃ | 170/184 | 170/184 | 184/193/204 | 193/204 |
| feed water temperature | ℃ | 20 | 20 | 20 | 105 |
| radiation area | ㎡ | 4.21 | 6.43 | 10.55 | 16.95 |
| convection area | ㎡ | 20.68 | 39.23 | 90.45 | 134.87 |
| economizer area | ㎡ | 9.66 | 16.56 | 16.56 | 53.13 |
| valid grate area | ㎡ | 1.852 | 3.15 | 5.18 | 8.395 |
| applicable fuel | * | COAL | COAL | COAL | COAL |
| exhaust gas temperature | ℃ | 152/160 | 152/161 | 163/163.8/169.5 | 163/169 |
| design efficiency | % | 77.73/77.24 | 78.53/78.18 | 79.37/79.30/78.96 | 79.83/79.19 |
| fuel consumption | kg/h | 170.74/172.93 | 341.71/343.63 | 673.22/676.27/682.11 | 866.39/877.51 |
| max part size for delivery | mm | 5488*2254*2782 | 5694*2704*3324 | 6743*2954*3508 | 8244*2951*3704 |
| DZH 1 - 6 t Coal / BIomass Fired Steam Boiler Technical Parameters |
| Item No. | DZH1-1.0 | DZH2-1.0 | DZH4-1.25 | DZH6-1.25 |
| Rated steam output(t/h) | 1 | 2 | 4 | 6 |
| Rated work pressure(Mpa) | 1 | 1 | 1.25 | 1.25 |
| Rated steam temperature(°C) | 184 | 184 | 194 | 194 |
| Rated feed water temperature(°C) | 20 | 20 | 20 | 20 |
| Thermal efficiency(%) | 77.18 | 76.8 | 78.8 | 78.5 |
| Fuel consumption (kg/h) | 172 | 358 | 726 | 1080 |
| Shipping size(m) | 4.31*1.9*2.86 | 5.41*2.6*3.1 | 5.86*2.8*3.39 | 6.2*2.96*3.58 |
Induced Draft
Fan | Model | Y9-19-6.3C | GY2-15 | Y6-41-7.1C | Y9-26-10D |
| Power(KW) | 5.5 | 11 | 18.5 | 45 |
Forced Draft
Fan | Model | 4-72-3.3A | GG1-15 | G6-41-6.4A | 4-72-5A |
| Power(KW) | 2.2 | 3 | 5.5 | 15 |
| Water Pump | Model | 1W2.4-10.5 | 11/2GC-5*7 | 11/2GC-5*7 | 2GC-5*6 |
| Power(KW) | 3 | 7.5 | 7.5 | 18.5 |
Grate Governor
Box | Model | WT-4 | WT-4 | WT-5 | WT-6 |
| Power(KW) | 0.55 | 0.55 | 0.55 | 1.1 |
| Slag Remover | Model | GBC-1 | GBC-2 | GBC-4 | GBC-6 |
| Power(KW) | 1.1 | 1.1 | 1.1 | 1.5 |
| Coal Conveyor | Model | FS-1 | FS-2 | FS-4 | FS-6 |
| Power(KW) | 1.1 | 1.1 | 1.1 | 1.5 |
