DZL horizontal biomass steam boiler,biomass
steam boilers,biomass boiler for sale,biomass pellet steam boiler
Why do people prefer biomass pellet steam boiler?
1. Because coal fuel, natural gas fuel, and oil fuel are
non-renewable resources.
However, biomass can indeed regenerate resources, and after good
treatment, it can be made into biomass particles, biomass
compressed blocks, and the like.
2. biomass pellet steam boiler are environmentally friendly. There is little pollution in the
combustion process, such as sulfides, which are low in content.
After dust removal treatment, it can be well purified.
3. biomass pellet steam boiler is environmentally friendly emissions have a long service life
Biomass steam boiler design advantages
1. The furnace has a double-tight coiled tube, which reduces the
heat load on the surface of the pipe and improves safety.
2. The Biomass steam boiler steering chamber design with the heating surface, which protects
the partition wall, avoid causing the partition wall falling off
and short-circuit phenomenon.
3. The medium flow is reasonable, the gas is conveniently
discharged as the gas is flowing from high place to low place.
Biomass Fired Boilers Application
1. Chemical industry: Steam is an indispensable source of heat and
power in petrochemical enterprises.
2. School: Students wash water
3. Hospital: for hospital appliances
4. Papermill: Steam is used in many parts of the papermaking
process.
5. Dairy factory: When the milk factory is produced, it needs a lot
of steam and hot water for sterilization and power.
6. Winery: Liquor is a kind of distilled liquor unique to China.
7. Food Factory: The hot water and steam generated by the boiler
are widely used in the process of distillation, extraction,
disinfection, drying, and maturation in food processing and
high-temperature steam is used to cook, dry and disinfect food.
Biomass steam boiler Technical data:
| DZH 1 - 6 t Coal / Biomass steam boiler Technical Parameters |
| Item No. | DZH1-1.0 | DZH2-1.0 | DZH4-1.25 | DZH6-1.25 |
| Rated steam output(t/h) | 1 | 2 | 4 | 6 |
| Rated work pressure(Mpa) | 1 | 1 | 1.25 | 1.25 |
| Rated steam temperature(°C) | 184 | 184 | 194 | 194 |
| Rated feed water temperature(°C) | 20 | 20 | 20 | 20 |
| Thermal efficiency(%) | 77.18 | 76.8 | 78.8 | 78.5 |
| Fuel consumption (kg/h) | 172 | 358 | 726 | 1080 |
| Shipping size(m) | 4.31*1.9*2.86 | 5.41*2.6*3.1 | 5.86*2.8*3.39 | 6.2*2.96*3.58 |
Induced Draft
Fan | Model | Y9-19-6.3C | GY2-15 | Y6-41-7.1C | Y9-26-10D |
| Power(KW) | 5.5 | 11 | 18.5 | 45 |
Forced Draft
Fan | Model | 4-72-3.3A | GG1-15 | G6-41-6.4A | 4-72-5A |
| Power(KW) | 2.2 | 3 | 5.5 | 15 |
| Water Pump | Model | 1W2.4-10.5 | 11/2GC-5*7 | 11/2GC-5*7 | 2GC-5*6 |
| Power(KW) | 3 | 7.5 | 7.5 | 18.5 |
Grate Governor
Box | Model | WT-4 | WT-4 | WT-5 | WT-6 |
| Power(KW) | 0.55 | 0.55 | 0.55 | 1.1 |
| Slag Remover | Model | GBC-1 | GBC-2 | GBC-4 | GBC-6 |
| Power(KW) | 1.1 | 1.1 | 1.1 | 1.5 |
| Coal Conveyor | Model | FS-1 | FS-2 | FS-4 | FS-6 |
| Power(KW) | 1.1 | 1.1 | 1.1 | 1.5 |
| Biomass steam boiler DZL QUICK INSTALLED BOILER |
| boiler model | Unit | DZL1-0.7/1.0-AII | DZL2-0.7/1.0-AII | DZL4-0.7/1.25/1.6-AII | DZL6-1.25/1.6-AII |
| capacity | ton/h | 1 | 2 | 4 | 6 |
| rated pressure | Mpa | 0.7/1.0 | 0.7/1.0 | 0.7/1.25/1.6 | 1.25/1.6 |
| rated steam temperature | ℃ | 170/184 | 170/184 | 184/193/204 | 193/204 |
| feed water temperature | ℃ | 20 | 20 | 20 | 105 |
| radiation area | ㎡ | 4.21 | 6.43 | 10.55 | 16.95 |
| convection area | ㎡ | 20.68 | 39.23 | 90.45 | 134.87 |
| economizer area | ㎡ | 9.66 | 16.56 | 16.56 | 53.13 |
| valid grate area | ㎡ | 1.852 | 3.15 | 5.18 | 8.395 |
| applicable fuel | * | COAL | COAL | COAL | COAL |
| exhaust gas temperature | ℃ | 152/160 | 152/161 | 163/163.8/169.5 | 163/169 |
| design efficiency | % | 77.73/77.24 | 78.53/78.18 | 79.37/79.30/78.96 | 79.83/79.19 |
| fuel consumption | kg/h | 170.74/172.93 | 341.71/343.63 | 673.22/676.27/682.11 | 866.39/877.51 |
| max part size for delivery | mm | 5488*2254*2782 | 5694*2704*3324 | 6743*2954*3508 | 8244*2951*3704 |
welcome for your inquiry any time!
