    Automatic Biomass Fired Steam Boiler For Food Industrial 1 - 10 Tons / H

    Ask Lasest Price
    Brand Name : YONGXING
    Model Number : DZL/SZL
    Certification : ISO9001,ISO14001,SGS,BV
    Price : negotiable
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : USD1000/SET
    Delivery Time : 10-15days
    • Product Details
    • Company Profile

    Automatic Biomass Fired Steam Boiler For Food Industrial 1 - 10 Tons / H

    Automatic 1 - 10tons / h Biomass Pellet Boiler For Food Industrial​


    Biomass Pellet Boiler Product Description

    The Biomass Pellet Boiler is developed by yongxing boiler, which is a kind of horizontal Three return water and fire tube boiler using biomass particles as fuel.

    The Biomass Pellet Boiler is fueled by renewable energy, which can not only reduce the cost of enterprises but also has the advantages of fast pressure rise, high thermal efficiency, large heating surface and so on.

    Biomass Pellet Boiler Main Features:

    1. Adopt threaded smoke pipe for heat transfer, and set the smoke pipe in the pot shell to reduce heat loss and improve thermal efficiency.

    2. Biomass Pellet Boiler has independent water processor, which can effectively improve the water quality of the boiler and extend the service life of the boiler.

    3. The use of advanced arch design, forming obvious "ɑ" flame, is advantageous to the disadvantage of coal combustion, increase fuel adaptability.

    4. The tail is equipped with a special dust collector, which can effectively filter the harmful gases in the tail gas and ensure that the dust meets the requirements of environmental protection.

    5. The high degree of automation, with automatic water regulation, low water level chain protection, high water level alarm, and other functions.

    6. The grate adopts the new small scale grate, adding unique safety ring, which makes the operation safe and reliable.


    Quality Assurance


    1. Strength calculation test report of applied materials
    2. The whole set of pure water processor line featured with RO anti-saturation and advanced testing devices
    3. Hydraulic test report: ensure the standard working pressure and safety
    4. Third-party inspection report-Jiao Special Equipment Inspection& Technical Research


    Quickly installed boiler
    boiler modelUnitDZL1-0.7/1.0-AIIDZL2-0.7/1.0-AIIDZL4-0.7/1.25/1.6-AIIDZL6-1.25/1.6-AII
    capacityton/h1246
    rated pressureMpa0.7/1.00.7/1.00.7/1.25/1.61.25/1.6
    rated steam temperature170/184170/184184/193/204193/204
    feed water temperature202020105
    radiation area4.216.4310.5516.95
    convection area20.6839.2390.45134.87
    economizer area9.6616.5616.5653.13
    valid grate area1.8523.155.188.395
    applicable fuel*COALCOALCOALCOAL
    exhaust gas temperature152/160152/161163/163.8/169.5163/169
    design efficiency%77.73/77.2478.53/78.1879.37/79.30/78.9679.83/79.19
    fuel consumptionkg/h170.74/172.93341.71/343.63673.22/676.27/682.11866.39/877.51
    max part size for deliverymm5488*2254*27825694*2704*33246743*2954*35088244*2951*3704
