Automatic thermal oil boiler system heating evenly meets the precise process temperature cycle heating

Thermal oil boiler system instructions

1. YLW coal and pellets fired thermal oil boiler system are horizontal, industrial use, automatic chain grate (traveling grate ) stoker, water tube compositional and forced circulation boiler.

2. Thermal oil boiler system takes coal, biomass pellet, wood pellet, sawdust, wood chips as fuel.

3. The front radiant heating area consists of a monolayer closely-arranged round coil.

4. The back convection heating area consists of snakelike coils.

5. Thermal oil boiler system includes the upper body and the below combustor.

6. The fuel burns in the lower combustor and the coils in the upper body absorb the energy and then transfer the heat to the medium.

Thermal oil boiler system Performance characteristics:

1, Obtain low-pressure high-temperature heat medium, easy to adjust, uniform heating, can meet the precise process temperature.

2, Liquid phase circulating heating, no condensation heat loss, heating system high thermal efficiency.

3, The working medium is subject to heat and heat release and the temperature rises and falls to the volume change, and there are compensation technical measures in the system.

4, Technical measures to strictly control the air, moisture and other low volatile matter content in the working medium before the cycle heating.

Industrial thermal oil heater features

1. Thermal oil boiler system is a new type of special boiler, with low pressure and high temperature working characteristics, it's heating temperature can reach liquid phase 340 ° C or vapor phase 400 ° C degree.

2. The organic heat carrier can be used for heating in any production occasion where the heating temperature is uniform and stable and the flame is not allowed to be directly heated. The heating temperature is between 150 °C and 380 °C.

3. Thermal oil boiler system generally uses coal, oil, and steam as fuel, and heat transfer oil as the medium. The hot oil circulation oil pump is used to force the medium to carry out liquid phase circulation, and the heat energy is transferred to the heat equipment and then returned to the heating furnace for reheating.

4. Thermal oil boiler system can get higher working temperature under low pressure and can control the operation of the medium with high precision.

5. Thermal oil boiler system has high heat utilization rate and convenient operation and maintenance. It is an ideal and safe choice for safety, high efficiency, and energy saving.

Thermal oil boiler system Applicable to:

1. Chemical industry - oleochemical, polymerization industry, reaction tank, distillation, concentration.

2. Plastic industry - plastic guns, extrusion stereotypes.

3. Textile industry - resin setting machine, dyeing machine, drying room, high temperature machine, roller machine.

4. The rubber industry - rubber vulcanization heating.

5. Food industry - cooking, drying, vegetable oil refining.

6. Forest industry--heating and setting of splint, Pauli board and fiberboard.

7. Paper industry - multi-layer cardboard packaging, drying, drying.

8. Others - heating of metal plating baths, coating condensation, drying, distillation, reduction, concentration, dehydration, etc.

YLW Industrial thermal oil heater DATA SHEET AND DRAWING

YLW Industrial thermal oil heater FAQ:

Dear friend,

Thanks for your time for scanning our products.

We need the following information to confirm the boiler model:

1.Boiler type: steam boiler, hot water boiler or thermal oil boiler?

2.Boiler capacity?

3. Boiler pressure?

4. Boiler application?

After confirming these questions, we will know exactly what boiler will be suitable for you and we will provide you our product details and quotation. Thank u.

Pls, click follow to send us the inquiry!

Welcome you any time!

Yongxing Boiler Group Co., Ltd. is a group company specializing in research, development, manufacturing, sales and installation services for various boilers and various thermal energy machinery and equipment.

Yongxing Boiler occupies an area of 60,000m2, with fixed assets of 15 million dollars, and is used for more than 100 sets of large and medium-sized equipment for production. More than 60 sets of advanced equipment for product quality inspection, with 37 series. The boiler and pressure vessel contains 167 specifications and models.

With A-class boiler manufacturing license issued by the General Administration of Quality Supervision, Inspection and Quarantine

A1 and A2 pressure vessel manufacturing licenses

The first-class boiler installation and transformation license

The ISO9001 international quality system certification and so on.

Annual production capacity is over 2000 tons.

YONGXING boiler main product:

Coal fired steam boilers, oil/gas steam boiler,hot water boilers, Thermal oil heaters, hot air furnace, oil/gas burners,chain grate accessories, and other environmentally friendly boilers and pressure vessels .

All the equipment are strictly enforced by the state and Industry standard, reasonable product design, advanced production technology, technical content in the country's similar products in a leading position, with compact structure, low noise, high thermal efficiency, safe and reliable operation, high degree of automation, etc.

All environmental indicators are in line with the national class I regional environmental protection standards require excellent products recommended by the environmental protection department.

Our company holds A-class boiler manufacturing qualification, A1, A2 pressure vessel manufacturing qualification and mechanical and electrical equipment installation engineering professional contracting qualification, and passed the international ISO9001 2000 quality management system certification.

Our company strictly follows the ISO9001 international quality management system guarantee model, carries out quality management and quality inspection and control activities, and the product quality is stable. It was rated as “Contract-honoring and Promise-keeping Enterprise” by the Henan Provincial Administration of Industry and Commerce, “National Honest and Law-abiding Enterprise” by the Ministry of Agriculture, and was included in the member unit by the China Quality and Technical Supervision Association, and has obtained a number of patented technologies.

Company honor:
