    High Temperature Thermal Fluid Boiler Low Pressure 1.25-3.5Mw Thermal Power 1.0Mpa

    Ask Lasest Price
    Brand Name : YONGXING
    Model Number : YY(W)L
    Certification : ISO9001,ISO14001,SGS
    Price : negotiable
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 1000sets/year
    Delivery Time : 10-15days
    • Product Details
    • Company Profile

    High Temperature Thermal Fluid Boiler Low Pressure 1.25-3.5Mw Thermal Power 1.0Mpa

    YLW Series High Temperature Low Pressure 1.25-3.5Mw Thermal Power 1.0Mpa Thermal Fluid Boiler


    Product Description

    YLW horizontal biomass Thermal Fluid Boiler is a forced circulation chain grate boiler developed by yongxing boiler. Thermal Fluid Boiler is composed of upper furnace body and lower chain grate, which is a new type of heating equipment with heat conducting oil as medium,The heat conducting oil is circulated by the thermal circulation pump to transfer heat to the thermal user equipment, and the heat conducting oil after the temperature drops is transported to the heating furnace for heating. The Thermal Fluid Boiler can realize accurate temperature adjustment and meet different requirements of temperature.

    Features

    1. Compared with coal burning, operating cost can be saved by 5%-10%, which is the best product to replace coal fuel.

    2. Good heat transfer performance and high thermal efficiency

    3. No corrosion and dirt will be generated during operation, and the later maintenance is convenient.

    4. Perfect operation control system and safety detection device, easy to operate.

    5. Compact structure, greatly saving boiler room floor space.

    6. The furnace is composed of double dense row coil, which reduces the surface temperature of the tube and improves the safety.


    VERTICAL YGL HAND FEED COAL/WOOD FIRED THERMAL OIL HEATER DATA SHEET

    Model dataYGL-120MAYGL-240MAYGL-350MAYGL-500MAYGL-700MAYGL-1000MAYGL-1200MAYGL-1400MA
    Rated thermal power Kw120240350500700100012001400
    Thermal efficiency%7373737373737373
    Design pressure Mpa0.60.60.60.60.60.60.60.6
    Medium higher temperature °C320320320320320320320320
    Cycle oil m3/h12.520406080100100100
    Piping connection diameter DN508080100100125125125
    Full system installed capacity Kw8101812225353535
    Coal burning typeⅡ,Ⅲ soft coal,BIOMASS PELLET
    Coal weight Kg/h285680100155185240290
    Boiler SizeDiameter mm12151500170017001960205021602290
    Height mm23102750306034753805441547605445
    Total weight Kg25003200480053005800620067007300

    VERTICAL YLL TYPE CHAIN GRATE AUTOMATIC COAL FEEDER THERMAL OIL HEATER DATA SHEET

    Model dataYLL-700MAYLL-1000MAYLL-1200MAYLL-1400MAYLL-2000MAYLL-2800MA
    Rated thermal power Kw70010001200140020002800
    Thermal efficiency%92
    Design pressure Mpa1
    Medium higher temperature °C350
    Cycle oil m3/h6080100100160180
    Piping connection diameter DN100100125125150150
    Full system installed capacity Kw25.931.543.4543.4562.7570
    Coal burning typeⅡ,Ⅲ soft coal,BIOMASS PELLET
    Coal weight Kg/h145180225270392535
    Boiler SizeL mm471047104710471058306390
    W mm208021702280228024502870
    H mm403346084855543058263450
    Total weight Kg108861181212980139352168028000

    YLW HORIZONTAL CHAIN GRATE TYPE THERMAL OIL BOILER HEATERS DATA SHEET

    projectUnitYLW-1400MAYLW-2000MAYLW-2400MAYLW-3000MA
    (120*104Kcal)(170*104Kcal)(200*104Kcal)(258*104Kcal)
    Rated thermal powerKW1400200024003000
    Thermal efficiency%≥73≥73≥73≥73
    design pressureMpa1.11.11.11.1
    Medium maximum temperature320320320320
    Circulating oilm3/h100160180200
    Piping connection caliberDN125150150150
    Full system installed capacityKW49.5757587
    Fuel typeMAMAMAMA
    Coal consumptionkg/h300400470565
    Dimensions (length * width * height)mm4703*2270*43005820*2270*39505820*2270*42596790*2270*4395
    total weightkg20500215002460033760

    High Temperature Thermal Fluid Boiler Low Pressure 1.25-3.5Mw Thermal Power 1.0Mpa

    High Temperature Thermal Fluid Boiler Low Pressure 1.25-3.5Mw Thermal Power 1.0Mpa

    Thermal Fluid Boiler FAQ:

    Dear friend,

    Thanks for your time for scanning our products.

    We need the following information to confirm the boiler model:

    1.Boiler type: Thermal Fluid Boiler

    2.Boiler capacity?

    3. Boiler pressure?

    4. Boiler application?

    After confirming these questions, we will know exactly what boiler will be suitable for you and we will provide you our product details and quotation. Thank u.

    It is ok to copy the question and answers directly when sending us the inquiry!

    Welcome you any time!
