    Most Energy Efficient Gas Boiler , Garment Fire Tube Condensing Boiler

    Ask Lasest Price
    Brand Name : Yongxing
    Model Number : WNS
    Certification : ISO9001,CE,ISO
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1-1000 set
    Delivery Time : 25 works day
    • Product Details
    • Company Profile

    Most Energy Efficient Gas Boiler , Garment Fire Tube Condensing Boiler

    Professional suppliers most efficient gas boiler and industrial gas boiler for garment factory used


    The WNS series condensing steam boiler adopts a wet-back three-return structure, and the smoke pipes are symmetrically arranged and evenly distributed. This structure can improve the stress distribution of the tube sheets. The combustion chamber of the most efficient gas boiler is completely immersed in water, and the cooling performance of the equipment is excellent. At the same time, the tube plate at the rear of the boiler is not washed by high temperature flue gas and has a long service life. According to different fuels, the high efficiency gas steam boiler can be divided into natural gas boilers, city gas boilers, coke oven gas boilers, liquefied petroleum gas boilers, and biogas boilers.


    Performance advantage
    1. Safe and durable
    The most efficient gas boiler has over-limit water level, over-limit pressure and over-temperature automatic protection function, which is safe and reliable.


    2. Beautiful appearance
    In the industrial gas boiler production process, advanced CNC machining technology is adopted, and the appearance is beautiful and generous.


    3. Energy efficient
    (1) The industrial gas boiler adopts a new energy-saving device to reduce the area of the energy-saving device and increase the heating area.
    (2) The combustion chamber area of the boiler is sufficient, and the corrugated furnace tube is used at the same time, which reduces the loss of thermal energy and improves the heat transfer efficiency.


    4. Compact structure
    The condensing steam boiler adopts a quick-loading structure, the equipment has a small footprint and the installation period is short.


    5. Easy maintenance
    The condensing steam boiler adopts the structure of the integral cigarette case for easy maintenance.


    6. Multiple controllers
    The boiler has the following three control modes for the user to select: common controller, LCD panel human-computer interaction type, man-machine dialogue remote control, etc.


    7. Application
    Heating, chemical, food, tobacco, textile, printing and dyeing, feed, medicine, building materials, brewing, rubber, hospital and so on.


    Most Energy Efficient Gas Boiler , Garment Fire Tube Condensing Boiler

    High efficiency gas steam boiler data Sheet

    Model

    Rated evaporation capacity(t/h)

    Working Pressure(Mpa)

    Steam Temperature(℃)

    Feed Temperature(℃)

    Transportation Size(m)(L×W×H)

    WNS1-0.7-Y(Q)

    1

    0.7

    170

    20

    3.3×1.8×2.1

    WNS1-1.0-Y(Q)

    1

    1

    184

    20

    3.3×1.8×2.1

    WNS2-1.0-Y(Q)

    2

    1

    184

    20

    4.4×2.1×2.5

    WNS2-1.25-Y(Q)

    2

    1.25

    194

    20

    4.4×2.1×2.5

    WNS4-1.25-Y(Q)

    4

    1.25

    194

    20

    4.7×2.5×2.9

    WNS4-1.6-Y(Q)

    4

    1.6

    204

    20

    4.7×2.5×2.9

    WNS6-1.25-Y(Q)

    6

    1.25

    194

    20

    5.9×2.6×3.0

    WNS6-1.6-Y(Q)

    6

    1.6

    204

    20

    5.9×2.6×3.0

    WNS8-1.25-Y(Q)

    8

    1.25

    194

    105

    5.9×2.8×3.1

    WNS8-1.6-Y(Q)

    8

    1.6

    204

    105

    5.9×2.8×3.1

    WNS10-1.25-Y(Q)

    10

    1.25

    194

    105

    7.7×2.8×3.1

    WNS10-1.6-Y(Q)

    10

    1.6

    204

    105

    7.7×2.8×3.1

    WNS15-1.25-Y(Q)

    15

    1.25

    194

    105

    7.0×3.1×3.6

    WNS15-1.6-Y(Q)

    15

    1.6

    204

    105

    7.0×3.1×3.6

    WNS20-1.25-Y(Q)

    20

    1.25

    194

    105

    8.3×3.4×4.0

    WNS20-1.6-Y(Q)

    20

    1.6

    204

    105

    8.3×3.4×4.0


    Packing List of high efficiency gas steam boiler

    Packing List
    1Boiler main part1 set
    2Imported gas/oil burner1 set
    3Electric control box1 set
    4

    Valve & Gauge used

    on boiler main part

    1 set
    5Feeding water Pump2 set
    6Smoke chimney1 set
    7Water treatment equipment1 set
    8Steam distributor1 set

    Natural Gas Steam Boiler Reference

    Boiler Reference of Gas/Oil Fired Steam Boiler
    NO.CountryModelApplication
    1IndonesiaWNS6-1.25-Y (Q)Textile industry
    2PakistanWNS1-1.0-Y (Q)Chemical plant
    3ThailandWNS1-1.0-Y (Q)Laundry industry
    4IndonesiaWNS2-1.0-Y (Q)Building industry
    5MalaysiaWNS8-1.25-Y (Q)Chemical industry
