    Horizontal Small Gas Fired Steam Boiler For Hotel Using New Design

    Ask Lasest Price
    Brand Name : Yongxing
    Model Number : WNS
    Certification : ISO9001,CE,ISO
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1-1000 set
    Delivery Time : 25 works day
    • Product Details
    • Company Profile

    Horizontal Small Gas Fired Steam Boiler For Hotel Using New Design

    New design horizontal gas fired boilers and small gas boiler for hotel with best price


    WNS series gas fired boilers are horizontal three pass fire tube wet back full automatic steam boiler. It normally suitable for 0.5t/h to 20ton/h capacity. According to different fuels, gas boilers can be divided into natural gas boilers, city gas boilers, coke oven gas boilers, liquefied petroleum gas boilers, and biogas boilers.


    1. The small gas boiler combustion chamber adopts corrugated furnace and low-position arrangement structure, which effectively increases the heat exchange area and reduces the adverse effects caused by the thermal expansion and contraction of the furnace.


    2. The small gas boiler adopts a three-return full wet back structure, which increases the heat exchange area and ensures high heat transfer efficiency.


    3. The operating state of the condensing steam boiler can be fully controlled by the program.


    4. The gas fired boilers has over-limit water level, flame out and over-pressure alarm protection functions to ensure the safe operation of the equipment.


    5. The gas fired boilers is equipped with imported well-known brand burners, and the fuel combustion efficiency can reach more than 86%.


    6, Can be widely used in hotels, schools, hospitals, textile factories, canteens, restaurants, food plants, pharmaceutical plants, packaging plants, building materials plants, swimming pools, etc.


    7. Advanced welding technology, high welding quality, and the qualified rate of flaw detection is over 99.99%.


    8. The method of micro-positive pressure combustion, the content of pollutants in the flue gas is very small.


    Horizontal Small Gas Fired Steam Boiler For Hotel Using New Design

    Commercial gas boiler data sheet

    Model

    Rated evaporation capacity(t/h)

    Working Pressure(Mpa)

    Steam Temperature(℃)

    Feed Temperature(℃)

    Transportation Size(m)(L×W×H)

    WNS1-0.7-Y(Q)

    1

    0.7

    170

    20

    3.3×1.8×2.1

    WNS1-1.0-Y(Q)

    1

    1

    184

    20

    3.3×1.8×2.1

    WNS2-1.0-Y(Q)

    2

    1

    184

    20

    4.4×2.1×2.5

    WNS2-1.25-Y(Q)

    2

    1.25

    194

    20

    4.4×2.1×2.5

    WNS4-1.25-Y(Q)

    4

    1.25

    194

    20

    4.7×2.5×2.9

    WNS4-1.6-Y(Q)

    4

    1.6

    204

    20

    4.7×2.5×2.9

    WNS6-1.25-Y(Q)

    6

    1.25

    194

    20

    5.9×2.6×3.0

    WNS6-1.6-Y(Q)

    6

    1.6

    204

    20

    5.9×2.6×3.0

    WNS8-1.25-Y(Q)

    8

    1.25

    194

    105

    5.9×2.8×3.1

    WNS8-1.6-Y(Q)

    8

    1.6

    204

    105

    5.9×2.8×3.1

    WNS10-1.25-Y(Q)

    10

    1.25

    194

    105

    7.7×2.8×3.1

    WNS10-1.6-Y(Q)

    10

    1.6

    204

    105

    7.7×2.8×3.1

    WNS15-1.25-Y(Q)

    15

    1.25

    194

    105

    7.0×3.1×3.6

    WNS15-1.6-Y(Q)

    15

    1.6

    204

    105

    7.0×3.1×3.6

    WNS20-1.25-Y(Q)

    20

    1.25

    194

    105

    8.3×3.4×4.0

    WNS20-1.6-Y(Q)

    20

    1.6

    204

    105

    8.3×3.4×4.0


    Packing List of condensing steam boiler

    Packing List
    1Boiler main part1 set
    2Imported gas/oil burner1 set
    3Electric control box1 set
    4

    Valve & Gauge used

    on boiler main part

    1 set
    5Feeding water Pump2 set
    6Smoke chimney1 set
    7Water treatment equipment1 set
    8Steam distributor1 set

    Boiler Reference of Gas/Oil Fired Steam Boiler
    NO.CountryModelApplication
    1IndonesiaWNS6-1.25-Y (Q)Textile industry
    2PakistanWNS1-1.0-Y (Q)Chemical plant
    3ThailandWNS1-1.0-Y (Q)Laundry industry
    4IndonesiaWNS2-1.0-Y (Q)Building industry
    5MalaysiaWNS8-1.25-Y (Q)Chemical industry
