    High Efficiency Gas Fired Steam Boiler For Beverage Factory 10 Ton

    Ask Lasest Price
    Brand Name : YONGXING
    Model Number : WNS1ton~20ton,1.25/1.6/2.5Mpa,Oil fired steam boiler
    Certification : ISO9001,ISO14001,A-CLASS,SGS,BV
    Price : negotiable
    Payment Terms : T/T,L/C,Western Union
    Supply Ability : 1000SETS/MONTH
    Delivery Time : 15-30DAYS
    • Product Details
    • Company Profile

    High Efficiency Gas Fired Steam Boiler For Beverage Factory 10 Ton

    10 Ton Gas Fired Industrial Steam Boiler High Efficiency Gas Steam Boiler Series For Beverage Factory


    1. Industrial Steam Boiler Quick Details:


    The Industrial Steam Boiler to make a horizontal tee wet backfire tube boiler, fuel mainly includes natural gas for oil and natural gas, LPG, LNG, CNG, city gas, methane gas, diesel oil, heavy oil, light oil, HFO fuel, is mainly used for: beverage factory, chemical plant, pharmaceutical factory, wood processing plants, plywood factory, LiQingChang, textile, food, dairy products processing factory, garment factory, hospital, etc.

    1. Evaporation capacity :500kg/h-20ton/h

    2. Design pressure: 1.0mpa (10bar), 1.25mpa (13bar), 1.6mpa (16bar), 2.5mpa (25bar)

    3. Stem temperature: under 224 degrees


    2. Industrial Steam Boiler Unique features


    1. Adopt the design of large-capacity combustion chamber and the world famous burner to improve the thermal efficiency of the boiler and reduce the failure rate of the boiler.

    2. Adopt integral spiral bellows design to increase heat transfer capacity and eliminate the influence of welding stress on Industrial Steam Boiler life.

    3. Full wet back structure, high heat resistance, high reliability, high maintenance rate, etc.

    4. With multiple safety interlocking protection devices, such as over temperature, overpressure, water shortage, power leakage, flameout, etc., to ensure safe and reliable operation


    High Efficiency Gas Fired Steam Boiler For Beverage Factory 10 Ton


    3. Industrial Steam Boilerr technique parameter


    Industrial Steam Boiler modelCapacityPressureFeed temp.Steam temp.Fuel consume.Thermal efficiency
    Light oilHeavy oil
    t/hMpakg/hkg/h%
    WNS1-1.0-Y(Q)112018465.567.391
    WNS 2-1.25- Y(Q)21.2520194129.6132.292
    WNS3-1.25-Y(Q)31.252019419219592.1
    WNS4-1.25- Y(Q)41.2520194256261.993
    WNS5-1.25- Y(Q)51.252019431832293
    WNS6-1.25- Y(Q)61.2520194380390.693.2
    WNS8-1.25- Y(Q)81.2510519450351793.5
    WNS10-1.25- Y(Q)101.2510519462864393.5
    WNS15-1.25- Y(Q)151.2510519494096593.5
    WNS20-1.25- Y(Q)201.251051941250130193.5

    High Efficiency Gas Fired Steam Boiler For Beverage Factory 10 Ton
