Simple Operating Gas Fired Steam Boiler Residential Total Weight Around 24 ton

    Buy cheap Simple Operating Gas Fired Steam Boiler Residential Total Weight Around 24 ton from wholesalers

    Buy cheap Simple Operating Gas Fired Steam Boiler Residential Total Weight Around 24 ton from wholesalers
    • Buy cheap Simple Operating Gas Fired Steam Boiler Residential Total Weight Around 24 ton from wholesalers

    Simple Operating Gas Fired Steam Boiler Residential Total Weight Around 24 ton

    Ask Lasest Price
    Brand Name : YONGXING
    Model Number : WNS1ton~20ton,1.25/1.6/2.5Mpa,Oil fired steam boiler
    Certification : ISO9001,ISO14001,A-CLASS,SGS,BV
    Price : negotiable
    Payment Terms : T/T,L/C,Western Union
    Supply Ability : 1000SETS/MONTH
    Delivery Time : 15-30DAYS
    • Product Details
    • Company Profile

    Simple Operating Gas Fired Steam Boiler Residential Total Weight Around 24 ton

    Simple Operating procedure WNS10-1.25-YQ 10 ton gas fired steam boilers residential total weight around 24ton


    gas fired steam boilers residential Description

    Our company has more than 50 years of production experience and has formed the production capacity of more than 200 varieties of 9 series including 9000 steam tons of power station boilers, industrial boilers, pressure vessels and power plant boilers. Users provide a large number of high quality, efficient and energy efficient boiler products.


    1. Gas fired steam boilers residential consists of the boiler main unit, the soot, and the piping system. The main engine and the soot part have been manufactured in the factory. The pipeline valves and instruments supported by the main machine have been randomly installed and transported to the site to host and The soot can be assembled.


    2. Test the vehicle by connecting the air source, power supply and water pipeline on site. The installation cycle is greatly shortened and the product quality is guaranteed.


    3. Joint control method using mechatronics control equipment and programmable logic controller (PLC). The advanced programmable logic controller (PLC) is the "central processor" of the control system. The control system is operated by the touch screen to make the boiler automatic control and reliable operation.


    4. Scientific product design, advanced processing technology, strict quality control, and the continuous operation life of all boiler equipment produced by our factory is more than 10 years. The radiant heating surface of the boiler is a full corrugated furnace, and the convection heating surface adopts a threaded tobacco tube. The heating surface is large, the boiler produces heat and the heat efficiency is as high as 92% or more, which is higher than the national regulations.


    gas fired steam boilers residential technical datasheet

    ModelOutputPressureTemperatureFuelTemperature
    (t/h)(Mpa)(ºC)(ºC)
    WNS0.5-0.7/1.0/1.25-YQ0.50.7/1.0/1.25170/184/194heavy oil/light oil, natural gas/LPG/city gas20
    WNS0.7-0.7/1.0/1.25-YQ0.70.7/1.0/1.25170/184/19420
    WNS0.8-0.7/1.0/1.25-YQ0.80.7/1.0/1.25170/184/19420
    WNS1-0.7/1.0/1.25-YQ10.7/1.0/1.25170/184/19420
    WNS1.5-0.7/1.0/1.25-YQ1.50.7/1.0/1.25170/184/19420
    WNS2-1.0/1.25/1.6-YQ21.0/1.25/1.6184/194/20420
    WNS3-1.0/1.25/1.6-YQ31.0/1.25/1.6184/194/20420
    WNS4-1.0/1.25/1.6-YQ41.0/1.25/1.6184/194/20420
    WNS5-1.0/1.25/1.6-YQ51.0/1.25/1.6184/194/20420
    WNS6-1.0/1.25/1.6-YQ61.0/1.25/1.6184/194/20420
    WNS8-1.25/1.6-YQ81.25/1.6194/20420
    WNS10-1.25/1.6-YQ101.25/1.6194/20420
    WNS12-1.25/1.6-YQ121.25/1.6194/20420
    WNS15-1.25/1.6-YQ151.25/1.6194/20420
    WNS20-1.25/1.6-YQ201.25/1.6194/20420

    Simple Operating Gas Fired Steam Boiler Residential Total Weight Around 24 ton

    Quality Simple Operating Gas Fired Steam Boiler Residential Total Weight Around 24 ton for sale
