6000Kw Coal Fired Thermal Oil Heater Energy Saving Thermic Fluid Boiler

    Buy cheap 6000Kw Coal Fired Thermal Oil Heater Energy Saving Thermic Fluid Boiler from wholesalers

    Buy cheap 6000Kw Coal Fired Thermal Oil Heater Energy Saving Thermic Fluid Boiler from wholesalers
    • Buy cheap 6000Kw Coal Fired Thermal Oil Heater Energy Saving Thermic Fluid Boiler from wholesalers

    6000Kw Coal Fired Thermal Oil Heater Energy Saving Thermic Fluid Boiler

    Ask Lasest Price
    Brand Name : YONGXING
    Model Number : YY(W)L
    Certification : ISO9001,ISO14001,SGS
    Price : negotiable
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 1000sets/year
    Delivery Time : 10-15days
    • Product Details
    • Company Profile

    6000Kw Coal Fired Thermal Oil Heater Energy Saving Thermic Fluid Boiler

    Complete in Specifications 140-6000Kw coal fuel thermal oil heater suppliers with high quality and low pressure


    thermal oil heater suppliers Features:

    1. The equipment has a fully automatic control system that can control and detect the operation of the heat transfer oil furnace throughout the process.

    2. The internal heat carrier of the coal-fired heat-conducting oil furnace can perform closed-circuit circulation to minimize heat loss, and the energy-saving and environmental protection effects are obvious.

    3. The thermal oil furnace has advanced technology, compact structure, beautiful appearance and high thermal efficiency. The structure of the heated surface is reasonably arranged and the equipment has a long service life.

    4. Compared with steam heating equipment, coal-fired heat-conducting oil furnace can save energy by 1-1.5 times, and can save energy by 1-1.3 times compared with electric heating and heating equipment, which greatly saves users' operating costs.

    The heating temperature of the equipment can reach 340 ° C, and the general working pressure can be less than 1 MPa.


    thermal oil heater suppliers Product advantages:

    1. Furnace body adopt unique patent technology, add top coiler, absorb flue gas waste heat and protect furnace top, so this improves service life of boiler.

    2. Fuel burn layer and adiabatic combustion, design patent energy-saving arch, burn sufficiently and improve thermal efficiency of boiler better.

    3. bi-coil design, safe & efficient heat conduction
    4. intelligent controller with PLC and touch screen, fully automatic operation
    5. well sealed boiler body & piping

    VERTICAL YGL HAND FEED COAL/WOOD FIRED thermal oil heater suppliers DATA SHEET

    Model dataYGL-120MAYGL-240MAYGL-350MAYGL-500MAYGL-700MAYGL-1000MAYGL-1200MAYGL-1400MA
    Rated thermal power Kw120240350500700100012001400
    Thermal efficiency%7373737373737373
    Design pressure Mpa0.60.60.60.60.60.60.60.6
    Medium higher temperature °C320320320320320320320320
    Cycle oil m3/h12.520406080100100100
    Piping connection diameter DN508080100100125125125
    Full system installed capacity Kw8101812225353535
    Coal burning typeⅡ,Ⅲ soft coal,BIOMASS PELLET
    Coal weight Kg/h285680100155185240290
    Boiler SizeDiameter mm12151500170017001960205021602290
    Height mm23102750306034753805441547605445
    Total weight Kg25003200480053005800620067007300

    VERTICAL YLL TYPE CHAIN GRATE AUTOMATIC COAL FEEDER THERMAL OIL HEATER DATA SHEET

    Model dataYLL-700MAYLL-1000MAYLL-1200MAYLL-1400MAYLL-2000MAYLL-2800MA
    Rated thermal power Kw70010001200140020002800
    Thermal efficiency%92
    Design pressure Mpa1
    Medium higher temperature °C350
    Cycle oil m3/h6080100100160180
    Piping connection diameter DN100100125125150150
    Full system installed capacity Kw25.931.543.4543.4562.7570
    Coal burning typeⅡ,Ⅲ soft coal,BIOMASS PELLET
    Coal weight Kg/h145180225270392535
    Boiler SizeL mm471047104710471058306390
    W mm208021702280228024502870
    H mm403346084855543058263450
    Total weight Kg108861181212980139352168028000

    YLW HORIZONTAL CHAIN GRATE TYPE thermal oil heater suppliers DATA SHEET

    projectUnitYLW-1400MAYLW-2000MAYLW-2400MAYLW-3000MA
    (120*104Kcal)(170*104Kcal)(200*104Kcal)(258*104Kcal)
    Rated thermal powerKW1400200024003000
    Thermal efficiency%≥73≥73≥73≥73
    design pressureMpa1.11.11.11.1
    Medium maximum temperature320320320320
    Circulating oilm3/h100160180200
    Piping connection caliberDN125150150150
    Full system installed capacityKW49.5757587
    Fuel typeMAMAMAMA
    Coal consumptionkg/h300400470565
    Dimensions (length * width * height)mm4703*2270*43005820*2270*39505820*2270*42596790*2270*4395
    total weightkg20500215002460033760
