Safety value small size water tube oil gas steam boiler with quality assured for Garment Factory

SZS fuel gas steam boiler -- equipment debugging instructions
Special note: after the equipment starts to work, the heating speed needs to be controlled, and the temperature cannot increase too fast.
Avoid boiler parts by heat is not uniform, produce too much stress, affect the service life of the boiler.

1. Before commissioning, the boiler should be thoroughly inspected (including accessories and pipelines) before supplying water to the boiler.
Discharge valve must be closed and air valves must be opened to allow air to escape before entering the water.

2. Supply water to boiler to normal water level according to the above method.

3. Open the burner (see the operation of the burner with the burner of the relevant information). At this point the burner enters the automatic control stage of the program. Purge, ignition, flameout protection and other automatic realization.

4. When there is a cast iron economizer, the circulation loop with the water tank should be opened. When there is a steel pipe economizer, the recirculation loop should be opened to protect the economizer at startup.

5. When there is superheater, the superheater outlet box of the vent valve, trap should be opened, so that steam cooling superheater.
Only when the main steam valve is opened to formally send steam to the pipe network, can close the superheater outlet box of the vent valve, trap.

Features

1. Full-film water wall structure
The boiler body design, the use of advanced all-water membrane type cold wall structure, the structure of the sealing performance is very good, strong reliability, compared with the traditional body structure, can effectively prevent smoke leakage.

2. Efficient heat exchanger
The steam boiler produced by the company is equipped with the corresponding energy-saving device, so that the condensing heat transfer effect of the boiler is more full, effectively improve the heat transfer efficiency of the boiler, smoke temperature is lower.

3. Wide range of fuel adaptation
The steam boiler produced by the company can be fueled by natural gas, liquefied natural gas, urban gas, biogas, etc., with a wide variety of fuel adaption, and users can choose more flexible fuel to meet the requirements of multi-fuel combustion.

Yongxing Boiler Group Co., Ltd. is a group company specializing in research, development, manufacturing, sales and installation services for various boilers and various thermal energy machinery and equipment.

Yongxing Boiler occupies an area of 60,000m2, with fixed assets of 15 million dollars, and is used for more than 100 sets of large and medium-sized equipment for production. More than 60 sets of advanced equipment for product quality inspection, with 37 series. The boiler and pressure vessel contains 167 specifications and models.

With A-class boiler manufacturing license issued by the General Administration of Quality Supervision, Inspection and Quarantine

A1 and A2 pressure vessel manufacturing licenses

The first-class boiler installation and transformation license

The ISO9001 international quality system certification and so on.

Annual production capacity is over 2000 tons.

YONGXING boiler main product:

Coal fired steam boilers, oil/gas steam boiler,hot water boilers, Thermal oil heaters, hot air furnace, oil/gas burners,chain grate accessories, and other environmentally friendly boilers and pressure vessels .

All the equipment are strictly enforced by the state and Industry standard, reasonable product design, advanced production technology, technical content in the country's similar products in a leading position, with compact structure, low noise, high thermal efficiency, safe and reliable operation, high degree of automation, etc.

All environmental indicators are in line with the national class I regional environmental protection standards require excellent products recommended by the environmental protection department.

Our company holds A-class boiler manufacturing qualification, A1, A2 pressure vessel manufacturing qualification and mechanical and electrical equipment installation engineering professional contracting qualification, and passed the international ISO9001 2000 quality management system certification.

Our company strictly follows the ISO9001 international quality management system guarantee model, carries out quality management and quality inspection and control activities, and the product quality is stable. It was rated as “Contract-honoring and Promise-keeping Enterprise” by the Henan Provincial Administration of Industry and Commerce, “National Honest and Law-abiding Enterprise” by the Ministry of Agriculture, and was included in the member unit by the China Quality and Technical Supervision Association, and has obtained a number of patented technologies.

Company honor:
