Factory directly sell screw type slag remover and scraper slag remover equipped coal boiler for textile mill

Screw slag remover Advantages

1. The spiral slag removing machine produced by the company has the characteristics of novel structure, stable and reliable operation, good wear resistance of cast steel body, long service life and outstanding function of slag.

2. The spiral slag removing machine and the horizontal boiler are installed at an inclination angle of about 40°. The lower part of the slag removing machine and the hopper are sealed by water to ensure no air leakage. The slag removal machine uses a wet slag removal method to avoid dust pollution in the ash slag.

3. The spiral slag removing machine has a compact structure and a small floor area. At the same time, the environment of the boiler room is very sanitary due to the material being transported in the sealed cylinder.

Screw slag remover Features:

1. Spiral slag removal machine can be used with horizontal quick-load coal-fired boilers to keep the boiler room clean and tidy, reduce gas pollution and reduce the labor intensity of the furnace workers. At the same time, the boiler can be burned under negative pressure, which further improves the thermal efficiency of the boiler.

2. The dusty ash should control the moisture content in the ash hopper. At the same time, it is forbidden to contain iron blocks, hard objects and unburned wood blocks into the cylinder to avoid jamming the screw shaft or damaging the mechanical device.

3. The transmission structure of the spiral slag removing machine is a worm gear, and the motor and the coupling are connected by rubber soft plates in the middle, which can effectively reduce vibration and mechanical wear. The first-stage shifting gear is a cylindrical helical gear, and the large gear drives the worm gear to function as a shifting gear. The worm gear is directly connected to the spiral main shaft to serve as a conveyor.

Boiler removal screw type
CZX TYPE (Length <8M Slag 0.6-2.3T/H)
For boiler 6ton/h~25ton/h

Yongxing Boiler Group Co., Ltd. is a group company specializing in research, development, manufacturing, sales and installation services for various boilers and various thermal energy machinery and equipment.

Yongxing Boiler occupies an area of 60,000m2, with fixed assets of 15 million dollars, and is used for more than 100 sets of large and medium-sized equipment for production. More than 60 sets of advanced equipment for product quality inspection, with 37 series. The boiler and pressure vessel contains 167 specifications and models.

With A-class boiler manufacturing license issued by the General Administration of Quality Supervision, Inspection and Quarantine

A1 and A2 pressure vessel manufacturing licenses

The first-class boiler installation and transformation license

The ISO9001 international quality system certification and so on.

Annual production capacity is over 2000 tons.

YONGXING boiler main product:

Coal fired steam boilers, oil/gas steam boiler,hot water boilers, Thermal oil heaters, hot air furnace, oil/gas burners,chain grate accessories, and other environmentally friendly boilers and pressure vessels .

All the equipment are strictly enforced by the state and Industry standard, reasonable product design, advanced production technology, technical content in the country's similar products in a leading position, with compact structure, low noise, high thermal efficiency, safe and reliable operation, high degree of automation, etc.

All environmental indicators are in line with the national class I regional environmental protection standards require excellent products recommended by the environmental protection department.

Our company holds A-class boiler manufacturing qualification, A1, A2 pressure vessel manufacturing qualification and mechanical and electrical equipment installation engineering professional contracting qualification, and passed the international ISO9001 2000 quality management system certification.

Our company strictly follows the ISO9001 international quality management system guarantee model, carries out quality management and quality inspection and control activities, and the product quality is stable. It was rated as “Contract-honoring and Promise-keeping Enterprise” by the Henan Provincial Administration of Industry and Commerce, “National Honest and Law-abiding Enterprise” by the Ministry of Agriculture, and was included in the member unit by the China Quality and Technical Supervision Association, and has obtained a number of patented technologies.
