Safe Natural Gas Hot Water Boiler Vacuum Diesel Fired Hot Water Boiler For Building Heating

    Buy cheap Safe Natural Gas Hot Water Boiler Vacuum Diesel Fired Hot Water Boiler For Building Heating from wholesalers

    Buy cheap Safe Natural Gas Hot Water Boiler Vacuum Diesel Fired Hot Water Boiler For Building Heating from wholesalers
    • Buy cheap Safe Natural Gas Hot Water Boiler Vacuum Diesel Fired Hot Water Boiler For Building Heating from wholesalers

    Safe Natural Gas Hot Water Boiler Vacuum Diesel Fired Hot Water Boiler For Building Heating

    Ask Lasest Price
    Brand Name : YONGXING
    Model Number : CWNS0.7-95/70-YQ
    Certification : ISO9001,ISO14001,A-CLASS,SGS,BV
    Price : negotiable
    Payment Terms : T/T,L/C,Western Union
    Supply Ability : 1000SETS/MONTH
    Delivery Time : 15-30DAYS
    • Product Details
    • Company Profile

    Safe Natural Gas Hot Water Boiler Vacuum Diesel Fired Hot Water Boiler For Building Heating

    0.35-5.6MW oil fired water boiler Vacuum Diesel Fired Hot Water Boiler for Building Heating


    Oil fired water boiler Vacuum unit performance characteristics

    1 safe and reliable
    2 integrated design, simplify the system; multi-functional, powerful
    3 low operating costs
    4 long service life
    5 automatic operation
    6 Save money and save floor space
    7 Easy procedure
    8 heat exchanger is easy to clean
    9 Meet environmental requirements
    10 low operating and maintenance costs

    Safe Natural Gas Hot Water Boiler Vacuum Diesel Fired Hot Water Boiler For Building Heating

    Why choose a vacuum hot water machine?


    1.The vacuum hot water machine is a special hot water supply equipment for heating, air conditioning and bath water with safety, energy saving and built-in secondary heat exchange device, which saves infrastructure and equipment investment, and saves the need for conventional hot water boilers.


    2.Heat exchanger unit and secondary operation system investment and operation electricity consumption, because the unit is a vacuum equipment, the machine can be used for long-term injection of heat transfer medium.


    3.Because of the deoxidation treatment inside the machine, there will be no oxygen corrosion inside the machine. The medium will not cause scaling on the surface of the built-in heat transfer tube, and the thermal efficiency is stable throughout the year. As early as the 1970s, Japan, the United States, and Germany have begun to use this technology.


    4.Now, hot water application engineering vacuum hot water machine has accounted for more than 70%, vacuum technology. Widely used. Our company has obtained national patent intellectual property rights since 1997, and produced the first vacuum hot water machine in China, and passed the provincial-level technical appraisal of HENAN Province. So far the products sell well all over the country.

    Safe Natural Gas Hot Water Boiler Vacuum Diesel Fired Hot Water Boiler For Building Heating

    Project / modelZKW0.7-85/60-Y(Q)ZKW1.05-85/60-Y(Q)ZKW1.4-85/60-Y(Q)ZKW1.75-85/60-Y(Q)ZKW2.1-85/60-Y(Q)ZKW2.8-85/60-Y(Q)ZKW3.5-85/60-Y(Q)
    Heat medium water capacity (L)4105205687008309801250
    Rated calorific value (Mw/h)0.71.051.41.752.12.83.5
    Rated calorific value6090120150180240300
    Fuel consumptionLight diesel oil (Kg/h)6496128160192256320
    Heavy oil (Kg/h)67.3100134168202269363
    Natural gas (m3/h)165116155193232310387
    City gas (m3/h)77247330412494659824
    Liquefied gas (m3/h)2944587388117146
    Heat ExchangerMaterial/structureStainless steel
    Working pressure (MPa)1
    HeatingMaximum calorific value36547290108144180
    Warm water circulation36547290108144180
    Pressure loss2.2322.62.53.53.3
    Heating outlet (DN)658080100125125133
    Heating area (m2)600090001200015000180002400030000
    Special for hot waterMaximum calorific valuetwenty four3648607296120
    Water supply capacity (m3/h)69121518twenty four30
    Hot water temperature50
    Pressure loss20.61.51.81.51.82
    Water outlet diameter (DN)40656580100100125
    VoltageVoltage (V)220/380
    Total power consumption2.2 (2.6)3.7 (4.1)5.0 (6.5)7.5(9)11 (2.5)15 (16.5)18.5(20)
    Blower power consumption2.23.757.5111518.5
    Oil pump power consumption0.40.41.51.51.51.51.5
    sizeChimney diameter (mm)350350400450500550600
    Long (m)2700320034004050470049005500
    Width (m)1365136516001600160018002020
    High (m)2345240025002580258026302700
