2000kw Stable Light Oil Burner Tank Diesel Fired Burner For Central Heating

    Buy cheap 2000kw Stable Light Oil Burner Tank Diesel Fired Burner For Central Heating from wholesalers

    Buy cheap 2000kw Stable Light Oil Burner Tank Diesel Fired Burner For Central Heating from wholesalers
    • Buy cheap 2000kw Stable Light Oil Burner Tank Diesel Fired Burner For Central Heating from wholesalers

    2000kw Stable Light Oil Burner Tank Diesel Fired Burner For Central Heating

    Ask Lasest Price
    Brand Name : YONGXING
    Model Number : YX35
    Certification : CE,ISO9001,ISO14001,SGS
    Price : negotiable
    • Product Details
    • Company Profile

    2000kw Stable Light Oil Burner Tank Diesel Fired Burner For Central Heating

    OEM support 2000kw oil burner price various fuel brenner gas burner for central heating with great price


    Advantages of oil burner price burners:
    A. Suitable for any liquid, gas fuel, one-button switching, easy to operate
    B. Mechatronics design, using proportional adjustment nozzle, swirling air distribution and flame stabilization device, atomization clean and efficient
    C. Easy to install, easy to disassemble, stable, safe, reliable, and guaranteed after sale
    D. Adopt automatic PLC program control, stepless adjustment control
    E. Electronic smoothing ratio adjustment, stepless adjustment device, energy saving safe and efficient


    ModelBurning barrel lengthMotor PowerweightfuelFlame detection method
    YXBarrel 120cm~3305cm0.37KW22KgDieselElectric eye
    Calorific valuecontrol methodpower supplyDimensionsIgnition methodNumber of nozzles
    350,000 kcalOne stage fire operation220V780mm × 455 mm × 373 mmElectronic ignition1

    Oil burner price Product application range:
    Steam, hot water, boilers, cooking stoves, spraying, hot air generators, baking equipment, melting furnaces, heating furnaces, incinerators, and other industrial furnaces

    The fully automatic gas burner is a kind of equipment that converts heat into energy through combustion, featuring high thermal efficiency and high safety.


    Fuel oil burner technical advantages:
    1. Heat evenly to prevent local overheating.
    2. The furnace is warmed up and the material is heated quickly.
    3. The pressure inside the furnace is even.

    4. Save fuel.
    5. Flue gas contains less nitrogen oxides and less noise
    6. Can achieve no emissions, no pollution.

    2000kw Stable Light Oil Burner Tank Diesel Fired Burner For Central Heating

    oil burner price data sheet for reference :

    Light Oil Burner YX5-YX350DSG BALTUR DESIGN
    MODELFUEL
    COMBUSTION
    BUR
    NER OUTPUT
    MAIN
    SUPPLY
    POWERCONTROL METHOD
    KG/HRKW
    MINMAXMINMAXWKV
    SINGLE STAGE BURNER
    YX5(ST120)25.62466220V1102*5S
    YX62.76.32466220V1102*5S
    YX105.21060.5116.6220V1102*5S
    YX104.51054118.6220V1202*5S
    YX2082095237220V1802*5S
    YX147.514.588.5171220V1502*5S
    YX187.61890213220V3702*5S
    YX261326154308220V3702*5S
    YX351533178391.4220V3702*5S
    YX341532178380380V3702*5S
    YX402045237534380V5502*5S
    TWO STAGE BURNER
    YX14DSG7.514.588.5171220V1502*5T
    YX18DSG10.522124.5261220V3702*5T
    YX26DSG1326154308220V3702*5T
    YX35DSG1533178391.4220V3702*5T
    YX34DSG1532178380380V3702*5T
    YX40DSG2045237534380V5502*5T
    YX55DSG2855332562380V11002*5T
    YX75DSG3575415880380V15002*5T
    YX100DSG451005331185380V22002*5T
    YX120DSG401404741660380V22002*5T
    YX180DSG601807122135380V30002*5T
    YX250DSG742708733185380V75002*5T
    YX300DSG11032513043854380V75002*5T
    YX350DSG11535013464151380V75002*5T
    BY LIGHT DIESEL OIL BURNER RIELLO DESIGN
    Burner
    model
    Suitable for boiler
    (TON/H)
    Burner thermal power
    (KW)
    Burner thermal power
    (MCAL/H)
    Oil Consume
    (KG/H)
    Fan power
    (KW)
    Applicable
    fuel
    Adjust
    Method
    BY61300-1186255-102025-1001.5DIESEL OIL
    KEROSENE OIL

    0#diesel
    11.86Kwh/kg
    1.02x104kcal/h
    Z-two stage
    T-three stage
    R-Mechanical ratio control
    BY101.5600-1900520-164251-1603
    BY152770-2750663-237765-2324
    BY203890-3100765-268375-2617.5
    BY3041100-4100949-353993-34610
    BY3551300-52601122-4549110-44412
    BY4061150-6100989-527397-51413.5
    BY5581900-87501642-7568160-73815
    BY70101900-105001642-9030160-88522
